PEEK 3D printing material is highly sought after in the medical industry due to its excellent biocompatibility and ability to be sterilized, making it ideal for custom medical implants. Additionally, its outstanding wear resistance and high-temperature stability make it a preferred material for producing aerospace parts and automotive components that require superior durability and thermal performance.
Thermal Properties
Heat Deflection Temperature (ISO 75-1-2020): 280 °C (0.45 MPa), 155 °C (1.82 MPa)
Melting Point: 343 °C
Mechanical Properties
Tensile Modulus (ISO 527-1-2019): 3.5 GPa
Tensile Strength (ISO 527-1-2019): 78 MPa
Elongation at Break (ISO 527-2018): 2.5 %
Other Features
Excellent chemical, oil, and heat resistance
Max. Part Size:
180mm x 180mm x 200mm
Tolerance and Precision：
±300μm or ±0.3%
